Fibre rope crane (FRC)

Working better deeper

The new fibre rope crane with a range of up to 400t is designed for continuous operation in a tough and corrosive offshore environment with focus on efficient and safe load handling.

WATCH

Fibre rope crane (FRC)

A range of offshore cranes up to 400 tonnes load using field proven Rolls-Royce fibre rope handling technology is now launched. The crane structure has an integrated operator cabin and the fibre rope runs over large diameter sheaves. Below deck is a compact CTCU (cable traction control unit) which forms the crane winch, provides active heave compensation and stores the rope on a reel. This system has a proven track record of more than 10 years. Particular attention has been made to ease of access and maintenance of all main components.

Because the selected rope has neutral buoyancy, the crane can handle loads to its full rated capacity down to 4,500 metres water depth. Cranes using heavy steel wire must begin derating at depths more than about 700m, so by 2,500m a 400t wire crane can only handle the same load as a 250t FRC.

Our rope management system monitors rope condition enabling abraded or damaged sections to be easily repaired by splicing onboard.

View all

SWL	150t	250t
Operating depth (m)	4500	4500
Min outreach (m)	7	11
Max outreach (m)	31	40
Winch speed (m/s)	0-1.5 (all layers)*	0-1.5 (all layers)*
AHC capacity (peak to peak)	4.8m at 10s period (all layers)*	3.2m at 10s period (all layers)*
Heavy lift capacity (double fall)	300t at 2250m	500t at 2250m
Aux winch capacity	10t / 20t	10t / 20t
Tugger winch capacity (t)	5	5
Slewing	+/- 200 degrees rotation	+/- 200 degrees rotation
Peak power consumption (kW)	1300	2300
Certification	DNVGL-ST-E407 'Rope-based deployment & recovery systems for designed service'

Approximate values provided for guidance only. Specifications may vary for given applications.
*Varies according to applied load

Field proven CTCU technology for fibre rope handling
Smart integration in vessel – below deck
Innovative crane structure – reduced weight
High-end control system
Active heave compensation
Constant tension, with auto landing and auto lift-off mode
Pull limit and controlled emergency pay-out function
State-of-the-art operator cabin
High quality – low maintenance, robust and field proven technology
Cost efficient logistics for rope replacement
In-field splicing of rope
Easy inspection of rope
Rope management system – full wear traceability
DNV GL certification

Auxiliary winch
Personnel lifting
Tugger winches
Remote access
Anti-collision system
Pedestal
Heavy lift double fall arrangement
Health monitoring
